400A / 600MCM Power Input Panels

Supporting up to 400 Amps per panel and 600 MCM cable lugs on the wireway side, Roam's MTC® 6003 IESHKvB series ("v" = Voltage Code) of Power Input Panels provides a rugged and cost-effective exterior connection point for temporary power input to trailers, buses, or temporary structures.

Roam's 400A-600MCM Power Input Panels use E1016 (J-Series/16 Series) Male Cam-Lok* brand connectors supporting up to 400A, along with bus bar extensions that support up to two 600 MCM cable lugs per connector. Roam's 400A-600MCM panels are constructed from powder coated aluminum and are also built with a dedicated wire chase (wireway) in the back to allow safe cable entry (via conduit) from the bottom.

Single Phase

MTC 6001 IESHK4B-BOY - 400A/480VAC - 1-Phase - Power Input Panel - Connection Panel - Tap Box - Docking Station - Bus Barred - Up to 600MCM Cable - Front View - Door Open - Single-Phase - Power Input Interface Box - 277VAC, 330VAC, 440VAC, & 480VAC - 480v (277v, 330v, 440v, & 480v) - 400A - Door Open - Showing E1016 (J-Series/16-Series) Male Cam-Lok Connectors - Cam-Lock - MTC6001IESHK4B-BOY - UL/cUL Listed

Three Phase

MTC 6003 IESHK4B-BOY - 400A/480VAC - 3-Phase - Power Input Panel - Connection Panel - Tap Box - Docking Station - Bus Barred - Up to 600MCM Cable - Front View - Door Open - Three-Phase - Power Input Interface Box - 277VAC, 330VAC, 440VAC, & 480VAC - 480v (277v, 330v, 440v, & 480v) - 400A - Door Open - Showing E1016 (J-Series/16-Series) Male Cam-Lok Connectors - Cam-Lock - MTC6003IESHK4B-BOY - UL/cUL Listed
